X-431 PAD7 LINK

LAUNCH High-end Flagship Diagnostic Tool
The X-431 PAD7 LINK is an unexpected high-end diagnostic tool from LAUNCH, comes with the ADAS calibration function, 41 service functions, TPMS service and multiple extended modules functions. New Smartlink C VCI powers technicians a new diagnostic level without the limitation of diagnostic functions, tools and vehicle types.
Related Products
X-431 PAD V LINK
X-431 PAD V LINK
Ultimate Scanner, Maximum Performance
X-431 PRO 5
X-431 PRO 5
New Era Of Smartlink Remote Diagnosis
X-431 PRO3 V4.0
X-431 PRO3 V4.0
Consumer Choice For Years
X-431 PRO V4.0
X-431 PRO V4.0
Best Seller For Years
X-431 PAD III V2.0
X-431 PAD III V2.0
Strong & Stable Diagnostic Tool
Features

1. Full system vehicle coverage for U.S., Asian and European markets over 110 brands, which is continually updated.

2. Upgrade and expand the X-431 PAD VII LINK with more software and service via the new module 'MALL' as demanded.

3. Real-time voltage display helps technicians to monitor the voltage condition of vehicle during the diagnosis.

4. Topology mapping gives a visual checking on DTCs and all systems communication status.

5. X-431 FIX diagnostic database providing detailed interactive wiring diagrams and illustrations enables technicians to complete every repairing job.

6. Support automotive communication protocols CAN/CANFD/DoIP and automotive communication standards J2534.

7. Auto-detects the communications protocol of the vehicle and assists to check automotive OBDII port pin damaged or not.

8. Intelligent diagnostic enables identify VIN automatically and access the system quickly.

9. Guided function for VW and AUDI.

10. Optional ADAS calibration function increases more revenue.

11. Advanced coding and programming function.

12. An extended solution to support TPMS service.

13. 2.4GHz & 5GHz dual-band communication ensures quick and stable connection.

14. Empower technician to diagnose light, medium & heavy-duty vehicles with Smarlink C.

15. The basic functions include reading & clearing DTC, remote diagnosis, Bi-directional control, live data graph, wireless software update etc.

16. Build-in repair information and training video modules help to track and fix issues fast.



Specification


  X-431 PAD7 LINK

  Operation System

  Andorid 9.0

  CPU

  2.0GHz Octa-core

  Display

  13.3' touch screen 1920*1080

  Memory

  8GB

  Storage

  256GB

  Camera

  Rear 13MP, Front 8MP

  Battery  9360mAh @7.6V/71.1Wh
  WiFi

  Dual Band 2.4 & 5GHz

  Diagnostic Communication

  WiFi

  Working Temperature

  0℃~50℃

  Dimension

  353*236*71 mm



  SMARTLINK C V2.0

  Display

  3.95''  320*480

  Memory

  256M

  Storage

  8GB

  Remote Communication

  Local Diagnosis: WiFi/BT/USB

  SmartLink Remote Diagnosis: WiFi/Ethernet

  Working Voltage

  9V DC ~ 36V DC

  Dimension

  200*110*47 mm
